STM32 Target Support Library Component Reference

This chapter lists the blocks of the PLECS STM32 Target Support Library in alphabetical order.

Analog In	Output the measured voltage at an analog input channel, in continuous mode
Analog In (Triggered)	Output the measured voltage at an analog input channel, in single or triggered mode
Base Task Load	Provide the CPU load generated by the base task as a percentage of the base task period
CAN Port	Set up a CAN communication port
CAN Receive	Receive CAN messages
CAN Status	Provide the CAN bus status
CAN Transmit	Transmit CAN messages
Control Task Trigger	Specify the base sample time and trigger for the main control tasks
DAC	Generate an output voltage from the input signal
Digital In	Read a digital input
Digital Out	Set a digital output
Edge Counter	Count edge of a pulse train
External Sync	External synchronization port for HRTIM and PWM blocks
HRTIM Master	Synchronize multiple HRTIM timing units for frequency and/or phase variable PWM signals
HRTIM Timing Unit	Generate up to two independent PWM signals or a complementary PWM signal pair
Offline Inport	Create a target inport for offline simulation
Offline Outport	Create a target outport for offline simulation
Override Probe	Allow modifying input value during a PIL simulation
Peak Current Controller	Implement peak current control with ramp compensation
Powerstage Protection	Provide powerstage safety features
Pulse Capture	Time-stamp edges of a pulse train
PWM	Generate a complementary PWM signal pair
Quadrature Encoder Counter (QEP)	Counts edges generated by a quadrature encoder
Read Probe	Provide read access to signal during a PIL simulation
SinCos	Fast calculation of sine and cosine
SPI Master	Implement SPI Master connected to one or multiple slaves
SPI Slave	Implement SPI Slave
Timer	Generate trigger signals for ADC and model
